12V (6.3-22V) In To 3.3V Out 3A 10W DC-DC Waterproof Converter Module
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Nominal Voltage Rating (DC) | 12 V |
| Mounting Style | Chassis Mount |
| Nominal Current Rating | 3 A |
| Plug Type | Wires (Flying Leads) |
| Current Conversion | DC to DC |
| Ripple & Noise | 150 mV |
| Color | Black |
| Nominal Power Rating | 10 W |
| Item Depth | 1.04 in |
| Minimum Operating Temperature | -25 °C (-13 °F) |
| Installation Area | Indoor/Outdoor |
| Brand | Envistia |
| Output Voltage Rating (AC) | N/A |
| Item Height | 0.55 in |
| Output Voltage Rating (DC) | 3.3 V |
| Inrush Current Rating | 3 A |
| Maximum Operating Temperature | 60 °C (140 °F) |
| Cable Length | 5.3 in |
| Country/Region Of Manufacture | China |
| Item Width | 1.81 in |
| Protection Properties | Open Circuit Protection |
This miniature waterproof DC-DC step-down converter module converts an 6.3V to 22V (nominally 12V) DC input to 3.3V DC output at up to 3A current (10W maximum). It features flying lead inputs and outputs for easy connection to your circuit. Specifications:Epoxy sealed plastic waterproof housing (IP68)Lightweight, compact, convenient to use and transportNon-isolatedProtection: Over-current, over-heating, short-circuit, reverse polarityAuto recoveryInput voltage: DC 12V nominal, will operate on any input voltage from 6.3V to 22V DCMaximum input current at 3A output: Approximately 0.83A at 12V input, 0.67A at 15V inputOutput voltage: 3.3VMaximum output current: 3AMaximum Output Power: 10WEfficiency: Typically 95%Voltage regulation: ±1%Load regulation: ± 2%Ripple (Full load test): < 150mVNo-load current: < 100mAOperating temperature: -25C - +60CSize (L x W x H): 46 * 27 * 14 mm / 1.81" x 1.04" x 0.55" (Length including mounting tabs is 64mm / 2.5")Weight: 36g / 1.3ozWaterproof rating: IP68Input and output wire length: 13.5cm / 5.3" (approx)Operating Notes:As with any DC-DC converter, the input DC power supply powering this converter must be capable of providing the maximum power drawn by your load. If the input supply is not capable of providing the power, the converter will fold back the output voltage as necessary. Example: If your load draws 3A at 5V (15W), and the input supply is only capable of providing 12V at 1A (12W), the maximum output voltage the converter will deliver is 4V (12W/3A).Package includes:1X 8V-23V Input to 5V Output 3A 15W DC-DC Step Down ConverterGet it faster! Stocks and ships from our US Colorado office for quick delivery. Contact us for quantity/OEM pricing. We provide FREE USPS First Class Shipping with Tracking - Not Economy Shipping
